Zephyr Debugging Woes: A Deep Dive Into Usability Issues

Debugging embedded systems, especially when dealing with complex RTOS like Zephyr, can be a challenging task. When integrating the Zephyr RTOS with the CMSIS Debugger, developers sometimes encounter a collection of usability issues that can impede their workflow. This article delves into the common problems faced when debugging Zephyr applications using the CMSIS Debugger, providing insights into the warnings, errors, and overall debugging experience.

Understanding the Zephyr Debugging Landscape

Before we dive into the specific issues, it's essential to understand the tools and technologies involved in debugging Zephyr applications. The Zephyr RTOS itself provides a robust framework for building embedded systems, supporting a wide range of hardware platforms. The CMSIS Debugger (specifically within the context of the CMSIS Debugger extension for VS Code), aims to streamline the debugging process by providing an integrated debugging environment. The combination of these technologies should, in theory, create a seamless debugging experience, however, in reality, there can be some hiccups, as detailed later in this article. Debugging these systems involves a few key components. Firstly, you have the GDB (GNU Debugger), which is a powerful command-line debugger used to inspect the execution of the code. Secondly, there are specific tools provided by chip vendors, that are used to connect and communicate with the target hardware. Finally, you have the debugger tools, like the VS Code extension, that can use all the tools to provide an integrated debugging experience. These tools work together to allow developers to set breakpoints, step through code, inspect variables, and analyze the behavior of their applications.

The Role of Debug Information

One of the critical components in the debugging process is debug information. This information is typically generated by the compiler and contains details about the source code, such as the names and types of variables, the location of functions, and the mapping between source code lines and machine code instructions. This debug information allows the debugger to display the source code alongside the machine code, making it easier for developers to understand what's happening in their code. The accuracy and completeness of this debug information are crucial for a smooth debugging experience. Any errors or inconsistencies can lead to issues such as incorrect variable values, misaligned source code displays, or even crashes of the debugger.

Common Zephyr Debugging Issues

While the CMSIS Debugger aims to simplify debugging, developers can sometimes encounter some challenges. These challenges can manifest as warnings, errors, or unexpected behavior within the debugging environment. Here's a closer look at some frequently reported problems:

Distracting Warnings in the Debug Console

One of the most common issues reported by developers is the appearance of warnings in the debug console. These warnings can be distracting and can impact the readability of the console output. While these warnings are often harmless, they can make it harder for developers to focus on the essential information provided by the debugger. These warnings usually originate from GDB (the GNU Debugger), but it's often unclear whether the root cause lies in the debug information generated by the compiler or how GDB interprets this information. The issue is usually related to how the debug information is structured or how it is interpreted by the debugger.

The Impact on Readability

When the debug console is cluttered with warnings, it becomes harder to identify critical debugging information. Developers may miss important messages or warnings related to the application itself, leading to extended debugging sessions and increased frustration. Therefore, addressing these warnings is important to improve the overall debugging experience.

Invalid state, unable to determine psp alias, assuming psp_s. Warnings

Another class of issues revolves around warnings that appear after hitting a breakpoint. These warnings, which often appear to be followed by hard GDB exits, can disrupt the debugging workflow. The exact cause of these warnings is not always immediately apparent, and the solution may require investigation into the interaction between the debugger, GDB, and the underlying hardware. These warnings often point to an issue with the debugger's ability to accurately determine the current processor state, leading to incorrect assumptions about the program's execution.

Potential Root Causes and Consequences

The Invalid state, unable to determine psp alias, assuming psp_s. warning often indicates a problem with the debugger's ability to determine the processor's current state. This can be caused by various factors, including incorrect debug information, hardware issues, or problems with the debugger's configuration. The consequences can range from incorrect variable values to the debugger crashing or exiting unexpectedly, leading to significant delays in the development process.

Hard GDB Exits

The hard GDB exits, which can sometimes follow the Invalid state warnings, are a serious issue. When GDB exits unexpectedly, the debugging session is terminated, and the developer must restart the debugging process. This can be very time-consuming, especially when debugging complex applications. The root cause of these exits can be difficult to identify, requiring thorough investigation of the debugger logs, the application code, and the hardware configuration. Solving this issue requires understanding the interaction between the debugger, GDB, and the target hardware. The sudden termination of the debugging session can lead to significant delays in the development process.

Reproducing the Issues: Example Projects

To help developers understand and reproduce these debugging issues, the article highlights two example projects that demonstrate the problems. These projects are based on the Zephyr-Alif and Zephyr-ST platforms, which are commonly used in embedded development. The instructions provided explain how to set up the CMSIS solution and the CMSIS Debugger extension. By using these projects, developers can replicate the problems and explore potential solutions.

Project Setup and Configuration

Setting up the example projects involves several steps, including installing the necessary tools, configuring the development environment, and building the application. The instructions for setting up the CMSIS solution and the CMSIS Debugger extension typically involve configuring the debugger settings, such as the target hardware, the debugger interface, and the GDB server. Developers need to make sure that these configurations are correct to ensure that the debugging process functions smoothly. Incorrect settings can often lead to the debugging issues described earlier.

Debugging Workflow with Example Projects

Once the projects are set up and configured, developers can start the debugging process by setting breakpoints, stepping through the code, and inspecting variables. The debugging workflow typically involves building the application, connecting the debugger to the target hardware, loading the program into the target, and then starting the debugging session. By working through these steps, developers can reproduce the issues described and gain a better understanding of the problems.

Expected Behavior and the Reality

Developers ideally expect a smooth debugging experience, where they can easily inspect the application code, set breakpoints, and examine the state of variables. However, the reality of debugging Zephyr applications with the CMSIS Debugger can sometimes be different. The issues described can disrupt the debugging process and impact developer productivity. These issues can often lead to frustration, extended debugging sessions, and delays in the development process. Understanding the root causes of these issues and implementing solutions are crucial to improve the debugging experience.

Additional Information and Resources

This article provides an overview of the issues encountered when debugging Zephyr applications with the CMSIS Debugger. The information included should help developers understand the problems they may face, helping them identify and resolve issues more efficiently. More information is usually provided by the developers of the tools used. The developers provide helpful documentation, tutorials, and community forums. These resources provide the latest information, solutions, and best practices for debugging Zephyr applications.

The Importance of Debugging

Debugging is a crucial part of embedded software development. It allows developers to identify and fix bugs, ensure that the application functions correctly, and optimize the code for performance. Effective debugging can lead to more reliable, efficient, and maintainable software. Therefore, it is essential to have reliable debugging tools and a well-understood debugging process.

Seeking Solutions and Improvements

Resolving these debugging issues requires a collaborative effort. Developers should report issues, provide feedback, and contribute to the community forums. This can help the developers of the tools understand the issues and work on solutions. Improving the debugging experience is crucial for embedded software development. By understanding the common issues, developers can take steps to improve their debugging workflow and increase their productivity.

Conclusion

Debugging embedded systems is an integral part of the software development lifecycle. By understanding the common debugging issues, developers can streamline the debugging process and improve their overall productivity. Addressing the issues described in this article, such as the distracting warnings and unexpected debugger exits, is essential for a more effective debugging experience. The solutions may require a combination of debugging techniques, tool updates, and community support. By working together, developers can create a more robust and reliable debugging environment.

For more information and insights, explore the official Zephyr Project documentation and the resources provided by the CMSIS-Pack developers.
