Introduction

Encountering compile errors can be a frustrating experience, especially when diving into custom builds and integrations. If you're working with ZMK and trying to integrate a dongle, you might stumble upon the dreaded 'pinctrl-0' is marked as required error. This article breaks down this error, explores potential causes, and provides a step-by-step guide to resolving it, ensuring a smooth compilation process and a functional ZMK-powered device. By understanding the intricacies of device tree overlays and pin control configurations, you'll be well-equipped to tackle similar issues in the future.

Understanding the Error Message

The error message

devicetree error: 'pinctrl-0' is marked as required in 'properties:' in /tmp/zmk-config/zephyr/dts/bindings/spi/nordic,nrf-spim.yaml, but does not appear in <Node /soc/spi@40004000 in '/tmp/zmk-config/zephyr/misc/empty_file.c'>

may seem cryptic at first, but it provides valuable clues about the problem. Let's dissect it piece by piece:

  • devicetree error: This indicates that the issue lies within the DeviceTree, a hardware description format used by Zephyr (the real-time operating system ZMK is built upon). The DeviceTree describes the hardware components and their configurations, allowing the system to understand and interact with the hardware.
  • 'pinctrl-0' is marked as required: This is the core of the problem. pinctrl-0 refers to a pin control configuration, which defines how the pins of a microcontroller are configured (e.g., as inputs, outputs, with pull-up resistors, etc.). The error states that this property is required in a specific definition file.
  • in 'properties:' in /tmp/zmk-config/zephyr/dts/bindings/spi/nordic,nrf-spim.yaml: This pinpoints the file where the requirement for pinctrl-0 is defined. The nordic,nrf-spim.yaml file likely describes the bindings for the SPI (Serial Peripheral Interface) controller on a Nordic Semiconductor nRF chip. Bindings files define the expected properties for hardware components.
  • but does not appear in <Node /soc/spi@40004000 in '/tmp/zmk-config/zephyr/misc/empty_file.c'>: This part tells you where the error is occurring. The SPI node (/soc/spi@40004000) in your DeviceTree does not have the pinctrl-0 property defined. The file /tmp/zmk-config/zephyr/misc/empty_file.c is a generated file and usually not the source of the error itself, but rather a consequence of the DeviceTree configuration.

In essence, the error message means that the SPI controller in your DeviceTree configuration requires a pin control configuration (pinctrl-0), but it's missing. This typically happens when the DeviceTree overlay that configures the dongle's SPI communication is not correctly setting up the pin control.

Common Causes of the 'pinctrl-0' Error

Several factors can lead to this error. Identifying the cause is crucial for applying the correct solution. Here are some common culprits:

  1. Missing or Incorrect DeviceTree Overlay: The most likely cause is an issue with the DeviceTree overlay file (.overlay) that configures the dongle. This file is responsible for adding or modifying nodes and properties in the DeviceTree, including the pin control settings for the SPI interface. If the overlay is missing, not applied correctly, or contains errors in the pin control configuration, this error will occur.

  2. Incorrect Pin Assignments: Within the DeviceTree overlay, the pin assignments for the SPI interface (MOSI, MISO, SCK, CS) might be incorrect. This means the overlay is trying to use pins that are not actually connected to the SPI controller or are already in use by another peripheral. Double-checking the pin mappings against your hardware schematic is essential.

  3. Conflicting Pin Configurations: Another possibility is a conflict in pin configurations. If another part of your configuration (e.g., the base keyboard configuration or another overlay) is using the same pins for a different purpose without proper pin control management, the conflict can trigger this error. Zephyr's pin control subsystem helps manage pin assignments, but misconfigurations can still lead to issues.

  4. Typographical Errors in the Overlay: DeviceTree syntax is strict, and even a small typo in the overlay file can prevent it from being parsed correctly, leading to this error. Carefully review the overlay file for any typos, especially in the pinctrl-0 definition and pin assignments.

  5. Incomplete or Outdated ZMK Configuration: If you're using an older version of ZMK or haven't fully updated your configuration after making changes, there might be inconsistencies that cause this error. Ensure your ZMK environment is up-to-date and that your configuration is consistent with the ZMK documentation and examples.

Step-by-Step Troubleshooting Guide

Now that we understand the error and its potential causes, let's walk through a systematic troubleshooting process:

1. Verify the DeviceTree Overlay File

The first step is to examine the DeviceTree overlay file responsible for configuring the dongle's SPI interface. This is often located in the zmk/app/dts/boards directory within your ZMK configuration. The specific filename will depend on your board and configuration, but it will typically have a .overlay extension.

  • Locate the Overlay File: Identify the correct .overlay file that applies to your dongle configuration. This might be specified in your Kconfig or CMakeLists.txt files.
  • Open the Overlay File: Use a text editor to open the .overlay file and carefully review its contents.

2. Inspect the Pin Control Configuration

Within the .overlay file, look for the section that defines the pin control configuration for the SPI interface. This section will typically include a pinctrl-0 property and a list of pins and their configurations.

  • Identify the SPI Node: Locate the SPI node in the overlay file. This is usually named something like spi0 or spi1 and will have an address (e.g., /soc/spi@40004000).
  • Check for pinctrl-0: Ensure that the SPI node has a pinctrl-0 property. This property should point to a pinctrl node that defines the pin configuration.
  • Examine the pinctrl Node: Find the pinctrl node referenced by pinctrl-0. This node will contain the pin definitions for the SPI interface (MOSI, MISO, SCK, CS).

3. Verify Pin Assignments

Carefully verify that the pin assignments in the pinctrl node match the actual physical connections on your hardware. Consult your hardware schematic or datasheet to confirm the correct pin mappings.

  • Compare with Schematic: Cross-reference the pin numbers in the pinctrl node with your hardware schematic. Ensure that the MOSI, MISO, SCK, and CS pins are correctly assigned.
  • Check for Conflicts: Make sure that the pins used for the SPI interface are not being used by other peripherals or functions in your configuration. Pin conflicts can lead to unpredictable behavior and compile errors.

4. Review the Bindings File

Refer to the bindings file (nordic,nrf-spim.yaml in this case) to understand the required properties for the SPI controller. This file defines the expected properties and their formats.

  • Locate the Bindings File: The error message provides the path to the bindings file (/tmp/zmk-config/zephyr/dts/bindings/spi/nordic,nrf-spim.yaml). However, you can also find it within the Zephyr repository in the dts/bindings directory.
  • Examine Required Properties: Open the bindings file and look for the properties: section. This section lists the required and optional properties for the SPI controller. Ensure that all required properties, including pinctrl-0, are present in your DeviceTree configuration.

5. Correct the DeviceTree Overlay

Based on your findings in the previous steps, make the necessary corrections to your DeviceTree overlay file.

  • Add Missing pinctrl-0: If the pinctrl-0 property is missing, add it to the SPI node and point it to a valid pinctrl node.
  • Correct Pin Assignments: If the pin assignments are incorrect, update the pinctrl node to use the correct pin numbers.
  • Resolve Pin Conflicts: If there are pin conflicts, reassign pins to avoid conflicts or use Zephyr's pin control API to manage pin assignments dynamically.
  • Fix Typographical Errors: Carefully review the entire overlay file for any typos or syntax errors.

6. Recompile and Test

After making the necessary corrections, recompile your ZMK firmware and test it on your device.

  • Clean the Build: Before recompiling, clean your build directory to ensure that all generated files are rebuilt. This can be done using the west build -t clean command.
  • Recompile the Firmware: Recompile your firmware using the west build command.
  • Flash the Firmware: Flash the newly compiled firmware to your device.
  • Test the Dongle Functionality: Verify that the dongle is working correctly and that the SPI communication is functioning as expected.

Example: Correcting a Missing pinctrl-0 Property

Let's illustrate how to correct a missing pinctrl-0 property. Suppose your .overlay file looks like this:

&spi1 {
 status = "okay";
 clock-frequency = <4000000>;
 // pinctrl-0 = <&spi1_pinctrl>; // Missing pinctrl-0
 cs-gpios = <&gpio0 10 GPIO_ACTIVE_LOW>;
};

The error message indicates that pinctrl-0 is missing. To fix this, you need to add the pinctrl-0 property and define a corresponding pinctrl node. Here's an example of how to do it:

&spi1 {
 status = "okay";
 clock-frequency = <4000000>;
 pinctrl-0 = <&spi1_pinctrl>; // Added pinctrl-0
 pinctrl-names = "default";
 cs-gpios = <&gpio0 10 GPIO_ACTIVE_LOW>;
};

&pinctrl {
 spi1_pinctrl: spi1_pinctrl {
  compatible = "pinctrl-single, pin-mux";
  #address-cells = <1>;
  #size-cells = <0>;

  spi1_default: spi1_default {
  group1 {
  psels = <NRF_PSEL(SPIM_SCK, 1)>, <NRF_PSEL(SPIM_MOSI, 2)>, <NRF_PSEL(SPIM_MISO, 3)>;
  };
  };
 };
};

In this example, we added the pinctrl-0 property to the spi1 node, pointing it to a new pinctrl node named spi1_pinctrl. We also defined the spi1_pinctrl node with the necessary pin configurations for the SPI interface.

Conclusion

The 'pinctrl-0' is marked as required error can be a stumbling block when working with ZMK and DeviceTree overlays. However, by understanding the error message, identifying the common causes, and following a systematic troubleshooting process, you can effectively resolve this issue and ensure a successful compilation. Remember to carefully examine your DeviceTree overlay file, verify pin assignments, review the bindings file, and make the necessary corrections. With a bit of patience and attention to detail, you'll be back on track to building your custom ZMK-powered devices.

For further reading and more in-depth information about DeviceTree and pin control, check out the official Zephyr documentation on Device Tree Bindings. This resource provides a comprehensive overview of DeviceTree concepts and best practices, helping you deepen your understanding and troubleshoot complex issues.
